HO scale railroad signal bridges.

More trackside signals  >>>  O scale   S scale  HO scale  N scale


Atlas 70000098 modern signal bridge, left hand

• For two parallel tracks
• Four signal heads with hoods
• Green, yellow and red LEDs
• Mounting base goes on the left side of the tracks, when facing the signal
• Height, base to top railing, 5.5 in (14cm)
• Width overall, 4.75 in (12cm)
• Track spacing, center-to-center, 1.75 in (45mm)
• Resistors are not included

Control this signal at a double track control point with a TS5 signal controller circuit.
Atlas left side signal bridge
Left side signal bridge
Atlas photo
Atlas signal connectors
Atlas signal connectors
The wires from these Atlas signals are terminated with 4-pin mini connectors, one connector for each signal head.

For easy connections to Azatrax or other non-Atlas controllers, use our signal breakout adapters [click here].
These adapters have built-in resistors.


Atlas 70000099 modern signal bridge, right hand

• For two parallel tracks
• Four signal heads with hoods
• Green, yellow and red LEDs
• Mounting base goes on the right hand side of the tracks, when facing the signal
• Height, base to top railing, 5.5 in (14cm)
• Width overall, 4.75 in (12cm)
• Track spacing, center-to-center, 1.75 in (45mm)
• Resistors are not included

Control this signal at a double track control point with a TS5 signal controller circuit.
Atlas right side signal bridge
Right side signal bridge
Atlas photo

Block signals in other scales  >>>  O scale   S scale  N scale
